Hermann Schwarz Laboratory

  • ZVA 24 four port vector network analyzer ranging from 10 MHz to 24 GHz
  • ZVL 6 vector network and spectrum analyzer ranging from 9 kHz to 6 GHz
  • SMBV 100 A vector signal generator with high output level and internal signal generation for all important radio standards. Frequency range: 9 kHz to 6 GHz
  • NRP-Z55 Thermal power sensor ranging from DC to 40 GHz with continuous measurement range from -30 dBm to +20 dBm
  • NRP-Z22 AVG power sensor ranging from 10 MHz to 18 GHz with measurement range from -57 dBm to +33 dBm

RF Measurement Laboratory

  • Vector Network Analysis raging from 300 kHz to 110 GHz
  • On-Wafer probing facilities up to 110 GHz
  • Spectrum analysis uo to 110 GHz
  • Noise figure and noise matching measurements up to 18 GHz
  • Several DC source measure units; thermochuck device
  • Time Domain Reflectometry up to 34 GHz

EMC Anechoic Chamber

For EMC analyses a 40 m² anechoic chamber is available. It is equipped with an EMI receiver and a broadband antenna, facilitating measurements from 9 kHz to 20 GHz with specified reflection conditions from the walls. For time-domain measurements a real-time oscilloscope with an analog bandwith of 1.5 GHz is available.
